In choosing the correct aggregate product for the application, some information and technical detail regarding the influence of various characteristics and properties is required.
Dewatering , Foundation support , Backfilling Retaining Wall, Dson Industries recommends G5.
For Gabions Applications
The performance of gabion structures depends not only on the type and quality of the gabion units specified but also the gabion filling materials chosen for both their mass and aesthetic appearance. In all events, the specified fill must be hard, durable and non-frost susceptible. Typical stone types indigenous to certain areas are illustrated below.
Quarried stones that are angular are the preferable fill with good interlock.
Crushed concrete although angular, tend to become rounded. It does have greater interlock than rounded stones, therefore 4mm wire diameter in Galfan coated or 3.8mm wire diameter for PVC welded wire mesh should be specified.
Rounded stones have a smoother face, therefore lower interlock potential, which can result in increased deformation of the unit’s face. Welded wire mesh gabions should be specified in 4mm or 5mm wire diameters for Galfan coated or 3.8mm wire diameter for PVC coated units to overcome this along with attention to detail during the construction process.
Blocky stone or flat stone when machine filled can result in large voids, which may result in settlements. Care should be taken when machine filling to minimise large voids.
Ideally, all gabions should be fair-faced (hand packed on the exposed faces). Where the cost of blocky stone or flat stone is high, the gabions can be filled with two types of fill: a blocky stone or flat stone for the exposed face with a cheaper quarried stone fill behind.
Base and sub-base materials are those materials that provide the supporting structure in any pavement design.
The table below provides G1 to G7 Crusher Run classifications
Material | Description |
---|---|
9,5mm Stone (-9,5mm to Dust) – Blasted, Crushed & Screened | GABION CLADDING TO STEEL SHEET PILES SUPPLY • INSTALLATION |
G1 (37mm Crushed) – Blasted, Crushed & Screened | Sound rock from an approved quarry, or clean, sound mine rock from mine dumps, or clean sound boulders |
G4 (37mm Crushed) – Blasted, Crushed & Screened | BARNES CONSTRUCTION |
G5 (53mm Screened) – Blasted / Mined, Crushed & Screened | |
G6 (63mm Screened) – Blasted / Mined, Crushed & Screened | |
G7 – Mined and selected oversize removed | |
Gabion Stone (-250mm + 100mm) | This is a very large crushed rock with 300mm – 100MM. Nominal Size |
G8 | Natural material (soil, sand or gravel) |
G9 | Natural material (soil, sand or gravel) |
